Hydraulic Lifting Wedge

Model HLW18W

Capacity 18 tons

Max. Spread 67.8 mm
FEATURES:
  • Specially designed to lift heavy loads in straight and vertical direction.
  • The HLW18W Spreader guarantees a safe and precise controlled movement of machines specifically during alignment jobs.
  • Applicable at minimum access gap of 9.5 mm.
  • Robust wedges to carry heavy loads with in a tight gap
  • Single-acting piston, spring return.
  • Lifting capacity: per step 19 mm lifting height.
  • Max. Wedge opening is 20 mm and Max. lift when using stepped block is 67.8 mm.
  • It is recommended that tools are used in pairs giving totally 36 Ton for an even and higher spreading force when needed.
Three different packages prepared:(More details on Package Components)
  1. HLW18W
  2. HLW18W-MAX
  3. HLW18W-TWINMAX
  • All packages are including safety block to remove the spreader and hold the loading.
Download Flyer Send us inquiry

Technical Specifications:

Model Capacity Operating Pressure

Spread

mm

Wedge Opening

 Min Required Gap

Max Flange Thickness

Weight
- Ton Bar Min Max mm mm mm Kg
HLW18W 18 700 9.5 67.8 20 9.5 N/A 8.5

Package Components:
Tool case includes:
Model: HLW18W
  • 1×Hyd. Lifting Wedge HLW18W
  • 1×Safety Block HLW18SF
  • 1×Stepped Block HLW18SB
MAX Package includes:
Model: HLW18W-MAX
  • 1×Hyd. Lifting Wedge HLW18W
  • 1×Safety Block HLW18SF
  • 1×Stepped Block HLW18SB
  • 1×Hand Pump SSH350S
  • 1×Gauge Dia. 60mm M0039
  • 1×Hose 1.8 meter PHS336
  • 2×Coupler CP332B
  • 1×Coupler CP331B
  • 1×Tadapter E1745
  • 1×Carry Case
TWINMAX Package includes:
Model: HLW18W-TWINMAX
  • 2×Hyd. Lifting Wedge HLW18W
  • 2×Safety Block HLW18SF
  • 2×Stepped Block HLW18SB
  • 1×Hand Pump SSH1000T
  • 2×Gauge Dia. 60mm M0039
  • 2×Hose 1.8 meter PHS336
  • 4×Coupler CP332B
  • 2×Coupler CP331B
  • 2×Tadapter E1745
  • 1×Carry Case
