Integral Hydraulic Lifting Wedge

Model HLW18I

Capacity 18 tons

Max. Spread 67.8 mm

FEATURES:

• Specially designed to lift heavy loads in straight and vertical direction.

• The HLW18I Spreader guarantees a safe and precise controlled movement of machines specifically during alignment jobs.

• Applicable at minimum access gap of 9.5 mm.

• Robust wedges to carry heavy loads with in a tight gap

• Single-acting piston, spring return.

• Max. Wedge opening is 20 mm and Max. lift when using stepped block is 67.8 mm.

• HLW18I has a built-in Hydraulic System, therefore the hand pump, hose and gauge are not necessary.

• The tool includes safety block to remove the spreader and hold the loading.

The Tool Case model HLW18I includes:

• 1×Hyd. Lifting Wedge HLW18I

• 1×Safety Block HLW18SF

• 1×Stepped Block HLW18SB
