Special Pump Head, PH series
Operating Pressure from 52 to 827 bar
To pressurize water or chemical liquids
FEATURES:
Large 3/8" pressure port for max. flow
Max. working pressure 827 bar
The aluminum alloy pump block manifold and forged pump housing are ideally for easy portability maneuvering and flexible fixture.
Can be used to pressurize water, chemical liquids to run the pipe leakage testing and maintenance jobs.
Wide range of operating pressure to select from.
Technical Specifications:
| Model |
Operating Pressure |
Volume per stroke | Max Handle Effort | Weight |
|---|---|---|---|---|
| - | bar | c.c | Kg | Kg |
| PH1003 | 827 | 2.36 | 30 | 4.4 |
| PH1004 | 448 | 3.8 | 25 | 5.5 |
| PH1006 | 206 | 8.5 | 26 | 5.9 |
| PH1008 | 69 | 14.7 | 15 | 6.1 |
| PH1012 | 52 | 34 | 26 | 5.7 |
